WiFi Smoke Detector Fire Alarm Device Fire alarm equipment Fire Alarm by TUYA
 Control and alert via the app When there is a fire
 Alarm 80 db
 No need to plug in, use AAA 1.5v batteries (2 batteries), long-lasting and economical. Battery indicator through the app
 Easy to install by yourself The app is easy to use.
 When the machine cover is removed Or running out of battery with notifications through the app immediately
 Various light status
 Normal safe
 The red light flashes every 60 seconds.
 There is no sound notification.
 Test system
 The red light is always on.
 Noisy Di-Di-Di
 There was a dangerous fire.
 The red light is always on.
 Noisy Di-Di-Di
 Low power (should replace 2 AAA batteries)
 Red light flashes 2 times every 60 seconds.
 There is no sound notification.
 Standby ready
 The red light is on for 15 seconds.
 No sound
 Automatic installation via WiFi
 Status light blinks every second
 No noise
 Custom installation
 The status light flashes every 3 seconds.
 No noise
 How to install WiFi Smoke Detector
 Install the TuyaSmart app by searching the name. Or scan the QR code in the manual
 Open the app, press the orange + sign button (top right) to add a device.
 Tap on Security & Sensors on the far left> Sensor (Wi-Fi) to connect to 2.4GHz WiFi (5GHz not receiving).
 Reset the device by pinching the RESET hole (on the side of the device) for 5 seconds or pressing the button near the battery holder for 5 seconds until the red light flashes multiple times.
 After RESET, it should be installed immediately, within 3 minutes, press Next and wait a moment, the system is searching for and connecting the adding device ...
 After the installation is complete The red light will stay on for a moment. You can set the device name in the app and press Done.
 Long press the test button. By pressing and holding on the status light of the machine for about 6 seconds to test the sound alert. And notifications via the app
 Install the unit to the kitchen ceiling. With a circle of 3M double-sided adhesive tape at all, or mount on the wall with bolts
 * For best performance Recommended to be installed in the open area in the middle of the room ceiling.
 * In the case of a very tilted roof (gable shape), install the distance from the center point or chicken breast 90cm.
 * Should find the installation point at least 30 cm away from the lamp and away from the wall corner Or the corner of the room at least 15 cm
 Device status in app
 No smoke alarm
 Safe, no smoke found on fire
 Notice, smoke detected
 Hazard detected smoke on fire
 How to change the battery
 Rotate the lower base slightly clockwise to unlock and pull the bezel off.
 Replace 2 AAA batteries and turn it (counterclockwise), close the cover back as before.
 What to receive
 Fire alarm detector
 At the RESET button
 Screw Nut Set for Wall Ceiling
 3M double-sided adhesive tape for wall mounting instead of drilling and fixing with nuts.
 English manual
 Specifications
 Input Voltage: DC3V LR03
 Static Current: <15uA
 Alarm Current: <160mA
 Low-voltage Notification: <2.4 V
 Alarm Sound Level: 70db / 1m
 WiFi: 802.11 b / g / n
 Detecting Range: 20 square meters
 Installation Method: Ceiling Mounted
 Working Temperature: -10 ° C ~ +50 ° C
 Wprking Humidity: <95% RH
 Size: 8 * 8 * 3.8 cm.
 * Recommended distance between the machine and the WiFi distribution router within 10 meters.
